Roller Spraying Machine
The roller spraying machine provided by RICHI is often used in the post-spraying process during the production of feed pellets, which can effectively increase the energy and fat content of feed pellets.
RICHI SYPG roller spraying machine, used for futher grease or heat sensitive materials to puffing and pelleting materials, suitable for powder、granule、crumbler feed, expansion and puffing materials.
At present, this post-spraying process has become a widely used method of adding oil in various feed production companies. This spraying method can not only improve the capacity level of the feed again, but also greatly improve the appearance and palatability of the pellet feed, thereby increasing the animal’s feed intake, increasing feed conversion rate, and making the feed quality recognized by the market.
+86 150 9316 3243
RICHI MACHINERY
How Does The Roller Spraying Machine Work?
The quantitative material is sent into the weighing hopper in the weighing system by the arc pneumatic gate in the feeding system, and the preparation before metering is carried out; the arc pneumatic gate is closed first, and the specific time for the quantitative material to be sent into the guide barrel via the belt conveyor is measured, and the conveying capacity of the conveyor is calculated; the material is sent into the guide barrel via the conveyor and is sprinkled out after the drum rotates. While the material rotates in the drum, the oil injection system starts to work.
The drum is tilted toward the outlet with an adjustable angle (usually adjusted to 5~6° first). A liquid spray pipe is installed in the middle with a compressed air atomizing nozzle on it. A flipping plate with a special angle is installed on the inner wall of the drum. As the drum rotates, the material is thrown up. The particles are sprayed with liquid during the throwing process. Various liquids such as grease and molasses can be sprayed.
RICHI MACHINERY
Advantages of Roller Spraying Machine
- Equipped with dynamic weight belt scale, weight measurement is significantly better than volume measurement;
- The injection ratio can be set, the computer PLC automatically controls the discharging amount ;
- The gear transmission roller does not slip, and the fully-sealed design has no leakage;
- Equipped with flowmeter imported from Germany, with high accuracy and small error of oil measurement;
- Equipped with two-fluid nozzle, the spraying uniformity is good;
- Automatic spray stop system without material induction, to prevent waste and pollution；
- The equipment uses a drum to keep the material moving, and the high-pressure nozzle sprays a mist liquid that fully contacts the surface of the feed to ensure uniform spraying.
RICHI MACHINERY
Roller Spraying Machine Parameters
RICHI can provide 1-15 tons per hour roller spraying machine to meet your production needs. The following are the parameters of some common models of roller spraying machines we produce:
| Model | SYPG800 | SYPG1000 | SYPG1200 | SYPG1400 |
| Main machine power（kw） | 1.5 | 2.2 | 3 | 4 |
| Capacity（t/h） | 1~3 | 4~6 | 8~12 | 13~15 |
| Diamater of drum（mm） | 800 | 1000 | 1200 | 1400 |
| Spraying oil proportion（%） | 1.5~6 | 1.5~6 | 1.5~6 | 1.5~6 |
RICHI MACHINERY
Precautions During The Operation of The Roller Spraying Machine
The following matters need to be paid attention to during the use of the roller spraying machine:
01 Pre-startup inspection
Before starting the machine, carefully check all connections to ensure there is no looseness, and check all pipes and other parts to ensure there is no leakage.
It is necessary to check whether the gear pump, liquid pump, and coupling are turning in the correct direction, and there should be no abnormal sounds such as sticking, collision, and friction.
02 Preparation before spraying
According to the needs, set the spraying amount range through the setting table on the panel. When liquid is added to the liquid storage tank, adjust the upper and lower limit contact positions of the electric contact thermometer to set the temperature range to 60-80℃. The liquid storage tank will automatically heat up to 60-80℃, and the system can now spray liquid.
03 Spraying machine start
Start the roller, belt feeding and gear pump in sequence, and the system will automatically control as needed to track and control the spraying amount.
RICHI MACHINERY
Roller Spraying Machine Can Be Customized
RICHI roller spraying machine is mainly used for spraying feed pellets and extruded pellets. It mainly sprays oil, molasses, vitamins, organic acids and other nutrients and medicines. It is especially suitable for producing high-energy feed.
Our roller spraying machine are customized according to the customer’s feed production line, so if you have any special needs, such as output, special spraying materials, etc., you can contact us directly and we can customize the drum sprayer for you according to your needs!
RICHI MACHINERY
Application of Roller Spraying Machine
RICHI can provide roller spraying machine with different materials suitable for various feed pellets, as well as other equipment and turnkey feed production projects required in the feed production process.
Roller Spraying Machine in Fish Feed Plant
It can be used for post-spraying of various floating aquatic feeds and sinking aquatic feeds.
Roller Spraying Machine in Pet Food Factory
We can provide roller spraying machine that meets the needs of pet feed spraying, producing pet feed with high fat content and good taste.
Roller Spraying Machine in Animal Feed Pellet Mill
Suitable roller spraying machine can be provided for feed mills according to the production needs of animal feed pellets.
